A Complete Guide to React Micro Frontend

It is a difficult and challenging task for developers to manage the entire codebase of the large scale application.  Every development team strives to find methods to streamline their work and speed up the delivery of finished products. Fortunately, concepts like micro frontends and microservices are developed to manage the entire project efficiently and have been adopted by application development companies.

Micro frontends involve breaking down the frontend side of the large application into small manageable parts. The importance of this design cannot be overstated, as it has the potential to greatly enhance the efficiency and productivity of engineers engaged in frontend code.

Through this article, we will look at micro frontend architecture using react and discuss its advantages, disadvantages, and implementation steps.

1. What are Micro Frontends?

The term “micro frontend” refers to a methodology and an application development approach that ensures that the front end of the application is broken down into smaller, more manageable parts which  are often developed, tested, and deployed separately from one another. This concept is similar to how the backend is broken down into smaller components in the process of microservices.

Read More on Microservices Best Practices

Each micro frontend consists of code for a subset (or “feature”) of the whole website. These components are managed by several groups, each of which focuses on a certain aspect of the business or a particular objective.

Being a widely used frontend technology, React is a good option for building a micro frontend architecture. Along with the react, we can use vite.js tool for the smooth development process of micro frontend apps.

2.1 Benefits of Micro Frontends

Here are the key benefits of the Micro Frontend architecture:

Here in this Reddit thread one of the front-end developers mentioned how React Micro frontend helps in AWS Cloudwatch.

Comment
byu/angle_of_doom from discussion
inAskProgramming

2.2 Limitations of Micro Frontends

Here are the key limitations of Micro Frontend architecture:

Please find a Reddit thread below discussing the disadvantages of Micro frontend.

Comment
byu/crazyrebel123 from discussion
inreactjs

Now, let’s see how Micro Frontend architecture one can build with React and other relevant tools.

3. Micro Frontend Architecture Using React

Micro Frontends are taking the role of monolithic design, which has served as the standard in application development for years. The background of monolithic designs’ popularity is extensive. As a result, many prominent software developers and business figures are enthusiastic supporters. Yet as time goes on, new technologies and concepts emerge that are better than what everyone thinks to be used to.

The notion of a “micro frontend” in React is not unique; instead, it represents an evolution of previous architectural styles. The foundation of microservice architecture is being extensively influenced by revolutionary innovative trends in social media, cloud technology, and the Internet of Things in order to quickly infiltrate the industry.

Because of the switch to continuous deployment, micro frontend with react provides additional benefits to enterprises, such as:

• High Scalability
• Rapid Deployment
• Effective migration and upgrading
• Technology-independence
• No issue with the insulation
• High levels of deployment and automation
• Reduced development time and cost
• Less Threats to safety and dependability have decreased

Let’s go through the steps of creating your first micro frontend architecture using react:

4. Building Micro Frontend with React and Vite

4.1 Set Up the Project Structure

To begin with, let’s make a folder hierarchy.

# Create folder named react-vite-federation-demo
# Folder Hierarchy
--/packages
----/application
----/shared

The following instructions will put you on the fast track:

mkdir react-vite-federation-demo && cd ./react-vite-federation-demo
mkdir packages && cd ./packages

The next thing to do is to use the Vite CLI to make two separate directories:

1. application, a react app which will use the components,
2. shared, which will make them available to other apps.

#./react-vite-federation-demo/packages
pnpm create vite application --template react
pnpm create vite shared --template react

4.2 Set Up pnpm Workspace

Now that you know you’ll be working with numerous projects in the package’s folder, you can set up your pnpm workspace accordingly.

A package file will be generated in the package’s root directory for this purpose:

touch package.json

Write the following code to define various elements in the package.json file.

{
  "name": "react-vite-federation-demo",
  "version": "1.1.0",
  "private": true,
  "workspaces": [
    "packages/*"
  ],
  "scripts": {
    "build": "pnpm  --parallel --filter \"./**\" build",
    "preview": "pnpm  --parallel --filter \"./**\" preview",
    "stop": "kill-port --port 5000,5001"
  },
  "devDependencies": {
    "kill-port": "^2.0.1",
    "@originjs/vite-plugin-federation": "^1.1.10"
  }
}

This package.json file is where you specify shared packages and scripts for developing and executing your applications in parallel.

Then, make a file named “pnpm-workspace.yaml” to include the pnpm workspace configuration:

touch pnpm-workspace.yaml

Let’s indicate your packages with basic configurations:

# pnpm-workspace.yaml
packages:
  - 'packages/*'

Packages for every applications are now available for installation:

pnpm install

4.3 Add Shared Component  (Set Up “shared” Package)

To demonstrate, let’s create a basic button component and include it in our shared package.

cd ./packages/shared/src && mkdir ./components
cd ./components && touch Button.jsx

To identify button, add the following code in Button.jsx

import React from "react";
import "./Button.css"
export default ({caption = "Shared Button"}) => <button className='shared-button'>{caption}</button>;

Let’s add CSS file for your button:

touch Button.css

Now, to add styles, write the following code in Button.css

.shared-button {
    background-color:#ADD8E6;;
    color: white;
    border: 1px solid white;
    padding: 16px 30px;
    font-size: 20px;
    text-align: center;
}

It’s time to prepare the button to use by vite-plugin-federation, so let’s do that now. This requires modifying vite.config.js file with the following settings:

import { defineConfig } from 'vite'
import react from '@vitejs/plugin-react'
import federation from '@originjs/vite-plugin-federation'
import dns from 'dns'

dns.setDefaultResultOrder('verbatim')

export default defineConfig({
  plugins: [
    react(),
    federation({
      name: 'shared',
      filename: 'shared.js',
      exposes: {
        './Button': './src/components/Button'
      },
      shared: ['react']
    })
  ],
  preview: {
    host: 'localhost',
    port: 5000,
    strictPort: true,
    headers: {
      "Access-Control-Allow-Origin": "*"
    }
  },
  build: {
    target: 'esnext',
    minify: false,
    cssCodeSplit: false
  }
})

Set up the plugins, preview, and build sections in this file.

4.4 Use Shared Component and Set Up “application” Package

The next step is to incorporate your reusable module into your application’s code. Simply use the shared package’s Button to accomplish this:

import "./App.css";
import { useState } from "react";
import Button from "shared/Button";

function Application() {
  const [count, setCount] = useState(0);
  return (
    <div className="Application">
      <h1>Application 1</h1>
      <div className="card">
        <Button onClick={() => setCount((count) => count + 1)} />
      </div>
      count is {count}
    </div>
  );
}

export default Application;

The following must be done in the vite.config.js file:

import { defineConfig } from 'vite'
import federation from '@originjs/vite-plugin-federation'
import dns from 'dns'
import react from '@vitejs/plugin-react'

dns.setDefaultResultOrder('verbatim')

export default defineConfig({
  plugins: [
    react(),
    federation({
      name: 'application',
      remotes: {
        shared: 'http://localhost:5000/assets/shared.js',
      },
      shared: ['react']
    })
  ],
  preview: {
    host: 'localhost',
    port: 5001,
    strictPort: true,
  },
  build: {
    target: 'esnext',
    minify: false,
    cssCodeSplit: false
  }
})

In this step, you’ll also configure your plugin to use a community package. The lines match the standard packaging format exactly.

Application Launch

The following commands will help you construct and launch your applications:

pnpm build && pnpm preview

Our shared react application may be accessed at “localhost:5000”:

At “localhost:5001”, you will see your application with a button from the shared application on “localhost:5000”:

5. Conclusion

Micro Frontends are unquestionably cutting-edge design that addresses many issues with monolithic frontend architecture. With a micro frontend, you may benefit from a quick development cycle, increased productivity, periodic upgrades, straightforward codebases, autonomous delivery, autonomous teams, and more.

Given the high degree of expertise necessary to develop micro frontends with React, we advise working with professionals. Be sure to take into account the automation needs, administrative and regulatory complexities, quality, consistency, and other crucial considerations before choosing the micro frontend application design.
